Product Overview
- Real-time vocal harmonies and high-quality effects in an affordable, easy-to-operate pedal
- Auto Harmony function automatically detects chords played on a connected guitar and generates perfectly matching harmonies, even during mid-song key changes
- Solo singers can create harmonies by manually setting the song key with a dedicated panel knob
- Hybrid mode creates harmonies based on both guitar chord input and the manual key setting, perfect for songs where the guitar part transitions between rhythm and lead playing
- 24 harmony types to choose from (12 one- and two-voice harmonies plus variations that provide even fuller sounds)
- Friendly user interface that’s simple to use, even for vocalists not familiar with using effects
- Easily dial up reverb and delay effects with a single knob
- Enhance function controls dynamics and applies subtle pitch correction as you sing
- Three memories for storing favorite settings
- Runs on four AA-size batteries or optional PSA-series AC adapter
- XLR mic input with phantom power (phantom power is available even when running on batteries)
- USB audio function for capturing processed vocal sounds into your computer
- Nominal Input Level
- MIC IN: -40 dBu (MicSens = Center)
GUITAR IN: -10 dBu - Input Impedance
- MIC IN: 4 k ohms
GUITAR IN: 1 M ohm - Nominal Output Level
- XLR OUT: -40 dBu
PHONES/LINE OUT: -20 dBu
GUITAR THRU: -10 dBu - Output Impedance
- XLR OUT: 600 ohms
PHONES/LINE OUT: 33 ohms - Effect Types
- HARMONY, ECHO, ENHANCE
- Number of Harmony Types
- 12 x 2(VARIATION)
- Number of Memory
- 3
- Connectors
- MIC IN jack: XLR type, balanced, phantom power (DC 48 V, 10 mA Max)
GUITAR IN jack: 1/4-inch phone type
GUITAR THRU jack: 1/4-inch phone type
XLR OUT jack: XLR type
PHONES/LINE OUT jack: Stereo miniature phone type
VARIATION, MEMORY INC jack: 1/4-inch TRS phone type
USB COMPUTER port: USB type B
DC IN jack - Power Supply
- Rechargeable Ni-MH battery (AA, HR6) x 4
Alkaline battery (AA, LR6) x 4
AC Adaptor (sold separately) - Current Draw
- 200 mA Max. (9 V)
- Expected battery life under continuous use:
- Rechargeable Ni-MH battery(*1): Approx. 12 hours (phantom power: OFF), Approx. 8 hours (phantom power: ON)
Alkaline battery: Approx. 11 hours (phantom power: OFF), Approx. 7 hours (phantom power: ON)
*1 When using batteries having a capacity of 2,450 mAh.
* These figures will vary depending on the specifications of the batteries and the actual conditions of use. - Accessories
- Owner's Manual
Leaflet “USING THE UNIT SAFELY”
Alkaline Battery (AA, LR6) x 4 - Options (sold separately)
- AC Adaptor (PSA series)
Footswitch (FS-5U, FS-6, FS-7) - Size and Weight
- Width
- 156 mm
6-3/16 inches - Depth
- 116 mm
4-5/8 inches - Height
- 64 mm
2-9/16 inches - Weight
- 600 g
1 lbs. 6 oz. - * 0 dBu = 0.775 Vrms
- ASIO is a trademark and software of Steinberg Media Technologies GmbH.
