Product Overview
- Special edition BOSS overdrive pedal with next-generation sound, feel, and response
- All-new design provides a superior playing experience that’s unattainable with analog overdrive pedals
- Powerful real-time processing delivers rich, wide-range sounds with natural compression
- Bold, high-definition tone that’s also smooth and refined
- Preserves the unique tonal characteristics of different guitars and pickup types
- Very low noise, even with high-gain settings
- Drive, High, and Low knobs offer a wide range of sound shaping not found in typical stompbox pedals
- Striking appearance with exclusive chrome knobs and control plate, plus vintage silver knob for battery compartment access
- Features BOSS’ innovative Multi-Dimensional Processing (MDP), realized with proprietary technology and custom DSP
- BOSS five-year warranty
- Nominal Input Level
- -20 dBu
- Input Impedance
- 1 M ohm
- Nominal Output Level
- -20 dBu
- Output Impedance
- 1 k ohm
- Recommended Load Impedance
- 10 k ohms or greater
- Bypass
- Buffered bypass
- Controls
- Pedal switch
LEVEL knob
LOW knob
HIGH knob
DRIVE knob - Indicator
- CHECK indicator (Serves also as battery check indicator)
- Connectors
- INPUT jack
OUTPUT jack
AC adaptor jack (DC 9 V) - Power Supply
- Alkaline battery (9V, 6LR61)
AC adaptor (sold separately) - Current Draw
- 65 mA
- Expected battery life under continuous use
- Alkaline: Approx. 6 hours
* These figures will vary depending on the actual conditions of use. - Accessories
- Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Alkaline battery (9V, 6LR61) - Option (sold separately)
- AC adaptor (PSA series)
- Size and Weight
- Width
- 73 mm
2-7/8 inches - Depth
- 129 mm
5-1/8 inches - Height
- 59 mm
2-3/8 inches - Weight
- 440 g
1 lb - * 0 dBu = 0.775 Vrms
