A potent selection of acoustic piano sounds and a variety of outstanding instrumental tones support a wide range of musical styles. These sounds are delivered through a powerful stereo speaker system that incorporates the latest audio processing and amplification technology that was developed in collaboration with the audio specialists at Onkyo. Access to sounds and features is by way of its intuitive panel design and sharp OLED graphic display, as well as the ES920’s convenient 4-band EQ faders that provide even more control. Bluetooth MIDI and Audio connectivity facilitates wireless enjoyment of many apps, such as Kawai’s PianoRemote, and listening to music from a smartphone or tablet through the ES920’s impressive audio system. Wired connectivity is also supported with standard MIDI, USB, and Line In/Out. At just 37 pounds the ES920 is surprisingly lightweight yet sturdy and delivers the most rewarding piano playing experience possible in a portable digital instrument
Highlights
- Responsive Hammer III keyboard action with redesigned key switches
- Improved acoustic piano sounds and updated Virtual Technician parameters
- Enhanced Touch Curve setting with 10 selectable touch presets
- Electric Piano, Drawbar and Jazz Organ, Electric Bass, Harpsichord, and Strings sounds
- Motherboard developed in partnership with Onkyo for improved tonal clarity
- Updated control panel with 4-band EQ faders and modern OLED graphic display
- Support for latest PianoRemote control app for iOS/Android
- Bluetooth MIDI and Audio functionality with aptX support for wireless audio playback
- Stylish rounded case design and lightweight chassis weighing 37.5 lbs
- Modern HM-5 designer stand and F-302 triple pedal bar (optional accessory)
- Compatible with the GFP-3 portable triple pedal unit (optional accessory)
.
Specifications
| Keyboard | Responsive Hammer III action - 88 keys - Grade-weighted hammers - Ivory Touch white key surfaces - Let-off simulation |
|
| Pedal | F-10H pedal unit - Damper (with half-pedal support) |
|
| Piano Sound | Harmonic Imaging XL (HI-XL) - 88-key stereo sampling - 256 note maximum polyphony |
|
| Piano Resonance | - Undamped String Resonance - Cabinet Resonance |
|
| Piano Adjustment | Virtual Technician (21 parameters) - Touch Curve (incl. User Touch Curve) - Voicing (incl. 88-key User Voicing) - Damper Resonance - Damper Noise - String Resonance - Undamped String Resonance - Cabinet Resonance - Key-off Effect - Fall-back Noise - Hammer Noise - Hammer Delay - Topboard Simulation - Decay Time - Release Time - Minimum Touch - Stretch Tuning (incl. 88-key User Tuning) - Temperament (incl. User Temperament) - Temperament Key - Key Volume (incl. 88-key User Key Volume) - Half-Pedal Adjust - Soft Pedal Depth |
|
| No. of Sounds | 38 | |
| Reverb | 6 types | |
| Other Effects | 11 types + 4 combination effects + amp simulator | |
| Speakers | (8 x 12) cm x 2 | |
| Output Power | 20 W x 2 | |
| Display | 128 x 64 pixel OLED | |
| Music Rest | Detachable type (included) | |
| Dimensions | Width | 52 3/4" (134.0cm) / |
| Depth | 14 3/4" (37.5cm) / 17" (43.0cm) | |
| Height | 5 3/4" (14.5cm) / 13 3/4" (35.0cm) | |
| Weight | 37.5 lbs (17 kg) | |
| Available Finishes | Black Snow White |
|
| Basic Functions | Dual Split Four Hands Transpose Tuning |
|
| Internal Songs | Sound Demo | 27 songs |
| Internal Recorder | Total Memory | approximately 90,000 notes |
| No. of Songs | 10 songs | |
| Parts | 2 track recorder | |
| Metronome | Time Signatures | 1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8, 7/8, 9/8, 12/8 |
| Drum Rhythms | Rhythm Section - 100 styles (x 2 variations) - 4-part accompaniment select - 100 preset chord sequences |
|
| Bluetooth * | Bluetooth (Ver. 4.1; GATT compatible) Bluetooth Low Energy MIDI Specification compliant, Bluetooth Audio |
|
| USB Audio Recorder | Record/Playback | MP3 WAV SMF |
| App Functions | Virtual Technician app (iPad) PianoRemote app |
|
| Connector Jacks | Headphone | 2 (1/4",1/8 “ )Stereo jacks |
| MIDI | MIDI IN, MIDI OUT | |
| Line Out | 1/4" L/MONO, R [unbalanced] | |
| Line In | 1/8" Stereo | |
| USB to Host | ✔ | |
| USB to Device | ✔ | |
| Others | Damper/Soft (for GFP-3/F-302) Damper (for F-10H) |
|
| Power Consumption | 18 W (PS-154 AC adaptor) | |
| Headphones | - | |
| Sheet Music | - | |
| Others | Warranty Card * Owner's Manual Music Rest F-10H damper pedal (with half-pedal support) |
